產品展示
PRODUCT適用于燃用各種煤質并配有消煙除塵裝置的0.2-20頓/小時
的工業鍋爐或生活鍋爐
輸送氣體溫度≤250°
90°、180°、0°三種安裝角度可調
型號:3.15C-12D共13個
Designed for various coal property burning 0.2-20t/h industrial
boiler or domestic boiler which is installed with smoke and dust
extracting equipment
Temperature of conveying air is below 250℃
There adjustable air outlet angles : 90°、180°、0°
Model no.:3.15C-12D, total 13 models
產品詳情
型號
Model |
電壓
Voltage |
配用電機 Matched motor (KW) |
轉速
Revolution |
流量
flow |
全壓 Total pressure (Pa) |
304整機價 304 overall price (RMB) |
風輪價 Wind turbine price (RMB) |
規格
Specifications |
3.15C |
380 |
1.5-2 |
2990 |
1218-2297 |
883-608 |
3600 |
1800 |
|
380 |
2990 |
1120-2112 |
745-520 |
|
||||
4C |
380 |
4-2 |
3300 |
2751-5190 |
1922-1393 |
5400 |
2300 |
|
380 |
3-2 |
2900 |
2417-4561 |
1481-1079 |
|
|||
5C |
380 |
7.5-2 |
2900 |
4723-8909 |
2324-1687 |
8400 |
2800 |
|
380 |
5.5-2 |
2620 |
4267-8048 |
1893-1373 |
|
|||
6C |
380 |
18.5-2 |
2850 |
8020-15129 |
3364-2452 |
11300 |
3600 |
|
380 |
15-2 |
2620 |
7372-13908 |
2844-2069 |
|
|||
7C |
380 |
22-2 |
2320 |
10367-19556 |
3040-2206 |
22000 |
|
|
380 |
15-4 |
2050 |
9159-17280 |
2373-1706 |
|
|||
8C |
380 |
30-4 |
2050 |
13474-25417 |
3001-2187 |
38000 |
7800 |
|
380 |
22-4 |
1860 |
12407-23404 |
2550-1853 |
|
